5.8dBi Fiberglass Antenna
Notice: The included antenna connector is RP-SMA male and it is fully compatible with RAK's WisGate Developer Gateways and Hotspot Miners. For compatibility with other devices, please check their documentation. If you want to know more about the connectors used in our devices you can see this blog.
The Second Generation of RAK LoRa Antennas is a high-performance omnidirectional monopole.
- White 5.8dBi Fiberglass Antenna
- Frequency: 860 - 930
- Gain: 5.1 ~ 5.8
- VSWP: 2
- Beamwidth: 360 degrees
- Impedance: 50 Ohms
- Polarization: Vertical
- Type: Dipole
- Radome Body: Fiberglass
- Connector: N-Type Male
- Bracket Inclusion: 2pcs brackets
- Dimensions: 800 ± 10mm
- Operation Temp: -40ºC ~ +60ºC
- Storage Temp: -30ºC ~ +75ºC
- Black 5.8dBi Fiberglass Antenna
- Frequency: 860~930 MHz
- Max gain: 5.9 dBi
- VSWR: ≤ 2
- High efficiency
- Vertically polarized monopole
- N-type connector
- Easy to mount with the included Installation kit
- 1pc Antenna
- 1pc Pigtail interface converter
- 2pcs Mounting brackets
