Outdoor Gateway Enclosure

Regular price $59.00 $0.00
Shipping calculated at checkout.

Product Description

Industrial Die-Cast Aluminum Design

Designed to withstand the toughest of environments, this enclosure is made of Industrial Die-Cast Aluminum. It is rated IP67/NEMA-6, making it completely protected from dust ingress and submergible up to 1m in water.

Complete documentation of this product can be found on our website documentation page.

Thermal Characteristics

  • Enclosure seal operating temperature range: -60°C to 230°C
  • Heat Trap: +6.5°C under full sun exposure (~ 100,000 Lux)
  • Temperature raise using a 5-10W heat source: +5.5°C

Ports

  • Ports For RAKBox-GW-1
    • 5x N-Type Antenna connectors
    • 1x Ethernet port (PoE supported)
    • 1x Reserved port
  • For RAKBox-GW-0
    • 2x N-Type Antenna connectors

Board Supports

  • RAK7249 DIY Gateway Boards
  • RAK831 Concentrator Boards

Packaging

  • Product Dimensions: 450mm x 300mm x 150mm
  • Product Weight: 3400g
  • Inclusions:
    • Enclosure together with connectors
    • Full assembly kit is included
  • Is the case big enough to put in a raspberry pi 4 + the rak2245 Pi hat (https://store.rakwireless.com/products/rak2245-pi-hat)?

    Hello Sir,

    Yes it is, however there are no mounting holes, so you should provide for a way to secure the devices yourself.

    Regards
    Vladislav
