Outdoor Unify Enclosure
Prefer another courier for your delivery? Contact us for special shipping arrangements.
Description
The Unify Enclosure for WisBlock is a modular IP67-rated outdoor enclosure that includes tailored features to support WisBlock Base Boards and WisBlock Modules. With a spacious internal, it is highly adaptable to any application and it is designed thoughtfully for universal mounting options.
Moreover, it supports different types of mounting options such as pole, wall, DIN rail, belt, and hook.
Features
- IP67 rated
- Material: ABS UL94V-0
- External Size: 150 x 100 x 50 mm (including lid)
-
Internal Space (usable space varies due to internal features):
- Approx. 138 x 88 x 35 mm in the widest region
- Narrowest point of the internal width = 60 mm
- General Wall Thickness: 4.5 mm
- Silicone waterproof seal (square profile to prevent twisting upon installation)
- Brass threaded inserts throughout (blind type)
- Logo customization possibility
- Support opening as required
Included in the Package:
- Unify Enclosure
- Silicon Rubber
- Mounting Plate
- Screw Plug
- IP67 Circular Connectors
- Screws
Documentation
