RAK Battery Plus

RAK9155 The Solar Battery Kit for LoRaWAN Gateways

SKU:910317

$739.00

Variant prices start at $739.00 to $817.00.

The shipping fee is calculated at checkout.
Prefer another courier for your delivery? Contact us for special shipping arrangements.

Quantity

Buy from your local authorized seller

Rokland is a RAK distributor in the US. They offer RAK Battery Plus, the best solar battery for LoRaWAN. Check their website regularly for promotions and availability.

Buy at Rokland

Choose Rokland for fast and local delivery.

Details
Specifications
Documentation
Q/A
Reviews

This solution includes everything to power the WisGate Edge Pro or WisGate Edge Prime (with Battery Plus support) gateway with Solar energy anywhere where reliable LoRaWAN coverage is needed.

Battery Plus, combined with the Solar Panel Kit, is the latest RAK battery system incorporating a solar panel, mounting kit, solar charging system, and status monitoring. It is specially developed for the WisGate Edge Pro and WisGate Edge Prime(with Battery Plus support) gateways. It will allow reliable outdoor deployment of the gateway in remote off-grid scenarios where the power is unreliable or inaccessible. Not only will your gateway be powered 24/7, but you will also get all the battery information and status in the WisGateOS Web UI locally and in the WisDM platform remotely.

With this 50ah battery, your gateway can run for more than 5 days without sun. The 80W panel is specially selected to meet the needs of the Battery Plus system and with the included mounting kit the solution can be deployed quickly and easily.

Enhance your commercial and large-scale deployments with the RAK Battery Plus, backed by a Product/Public Liability Certificate of Insurance for unparalleled reliability and risk mitigation in even the most remote locations.

Battery Plus Features

Long Life Span - The Lithium Iron Phosphate battery can be expected to remain serviceable for more than 10 years, considering that it is charged and discharged once a day at room temperature (25°C).
Integrated Heating Function - The battery integrates a solar charger and heater, it can be connected to PV panels directly and charged under 0°C.
Lightweight Design - The weight of RAK9155 is no more than 8kg making installation by a single person easier.
High Waterproof Grade - With an IP65 rating of the enclosure, RAK9155 is suitable for both indoor and outdoor environments.

Solar Panel Kit Features (included with the RAK Battery Plus & Solar Panel kit variant)

Peak power: 80 W
Open circuit voltage (Voc): 24.4V
power voltage (Vmp): 20.5V
power current (Imp): 3.90A
Dimensions: 795x580x30mm
Operating temperature: -40°C to +85°C
The pole diameter supported by the mounting kit is 50-100 mm

Note:

Change Notification for Solar Panel

Change Notification for Battery Plus

Bundle Inclusion

Battery Plus power solution with 50Ah battery
Solar Panel with mounting kit (if selected)
All cables for the connection between the Solar Panel, Battery Plus, and gateway are included

Package Inclusion

1pc Solar Battery
3pcs Power Cable
1pc Mounting Kit
3pcs Cable trap-Screw Mount
1pc Carry equipment

Ensure Optimal Performance

A dedicated Service Power Adapter for Battery Plus is available. Add it via the "Check to Include" option! It is suitable for the following purposes:

Initial Charging: Fully charge the Battery Plus in-house when received. Due to transportation limitations, the battery is charged to only 30%.
Long-term Storage: If you plan to store the Battery Plus for longer periods, fully charge the battery before storing it.
Deployment Preparation: Fully charge the Battery Plus before deployment to ensure it can power your solution.
Testing and Evaluation: Charge batteries during testing phases without the Solar Panel to verify their performance and longevity.

This adapter is an essential tool for maintaining and ensuring the efficiency of your RAK Battery Plus.

Documentation

Questions and Answers

Have a Question?

Be the first to ask a question about this.

Ask a Question

Product Reviews

Hardware	Nominal capacity: 50Ah Nominal voltage: 12.8V Operating Voltage Range: 10 ~ 14.6V Rated Energy: 640Wh Standard charging current: 0.16 C (8 A) Maximum Charging Continuous Current: 0.2 C (10 A) Standard Discharge Current: 0.16 C (8 A) Max Discharge Continuous Current: 0.2 C (10 A) Integrated battery heater
Environmental	Charge temperature: 0 ℃~55 ℃ Discharge temperature: -15 ℃～60 ℃ Operational humidity: 20~80% RH Storage Temperature: -20 ~ 50 °C Storage humidity: 0~100% RH noncondensing
Enclosure	IP65-rated outdoor enclosure. Material: plastic Dimensions(L/W/H): 499x280x75（±3) mm
Connectors and buttons	1x Load connector, 4 Pins, for connecting to RAK7289V2/CV2, RAK7240V2/CV2, or RAK power accessories – RAK9105U/P 2x PV Input for Solar panel/s On/Off button
Software	High-grade MPPT controller BMS system Battery Status and charge monitoring: Battery status available in the RAK WisGateOS Battery status available in the RAK WisDM remote management platform
