Soil pH Monitoring
pH monitoring Sensor
LoRaWAN/NB-IoT/Cellular IoT
Prefer another courier for your delivery? Contact us for special shipping arrangements.
Sensor Hub pH Value Monitoring is widely used in applications requiring ph monitoring, such as soil ph measurement to determine soil fertility. The product can be widely used in rice fields, greenhouse cultivation, vegetable cultivation, orchard nursery, flowers, soil research, and more.
The form factor of the Sensor Hub allows for multiple and/or different sensors to be connected at the same time, creating a full and versatile soil condition monitoring system. The Splitter cable can connect several Sensor Probes and Probe IOs to a single Sensor Hub port. The distance between the Sensor Hub and Sensor Probe/Probe IO can be extended via the Extension cable.
Note: Sensor Hub with Sensor Probe IO and connected sensor cannot be powered on batteries. You need to use the included power supply only.
The Sensor Hub has two variants based on the communication type - LoRaWAN only and LoRaWAN+NB IoT. SensorHub's NB-IoT module supports two types of LTE (Long-Term Evolution) categories, namely CAT M1 and CAT NB2. CAT M1 offers higher data rates and lower latency, while CAT NB2 provides ultra-low power consumption and greater coverage, making it an ideal choice for devices that operate on batteries and require long-term connectivity.
Features
- LoRaWAN/NB-IoT communication
- Durable design for outdoor applications
- Accurate and reliable measurements
- External DC power supply
- Solar panel power source (optional)
|
Parameter |
Value |
|
Measure range |
0~1999mg/kg |
|
Accuracy |
±2%F.s |
|
Resolution |
1mg/kg (mg/l) |
|
Working temperature |
+5~+45℃ |
|
Working humidity |
5~95%RH, no condensation |
Included in the package:
- 1 x Sensor Hub
- 1 x Sensor Probe IO
- 1 x pH Sensor
- 1 x Power supply for the Sensor Hub
- 1 x SensorHub Wall Mount
- 1 x Pole Mount for SensorHub φ65-89mm
-
1 x Screw Kit
Documentation
Questions and Answers
Have a Question?
Be the first to ask a question about this.
Product Reviews
- LoRaWAN/NB-IoT communication
- Durable design for outdoor applications
- Accurate and reliable measurements
- External DC power supply
- Solar panel power source (optional)
- LoRa 868-930 MHz support
- Based on RAK4630 (opens new window)(MCU: nRF52840, Radio Chip: SX1262)
- RUI3 (opens new window)- based code
- Auto-detection of the power source
- Auto-detection of the Sensor Probes
- 2~4 pcs 3.6 V ER18505 4000 mAh Li-SOCl2 primary lithium batteries
- 12 VDC over power supply or solar panel
- NB-IoT interface module (RAK5860 (opens new window)) support (optional)
- Embedded antenna
- High efficiency (over 75%) LoRa Band 860~930 MHz
- Support 700~960 MHz and 1700~2170 MHz.
- NFC tag for power on and smart connect over BLE
- Prevent theft via the hall effect sensor on the exclusive mounting bracket
- IP66-rated waterproof enclosure
- Sensor ports can host multiple Sensor Probes via Probe Splitters
- Off-grid deployment with RAK9154 Solar Battery (opens new window)add-on
|
Parameter |
Value |
|
Measure range |
0~1999mg/kg |
|
Accuracy |
±2%F.s |
|
Resolution |
1mg/kg (mg/l) |
|
Working temperature |
+5~+45℃ |
|
Working humidity |
5~95%RH, no condensation |
