WisMesh RP2040 Starter Kit

What Is WisMesh RP2040 Starter Kit?

Meshtastic is an off-grid messaging system. It relies on LoRa technology to establish mesh networks. Messages are forwarded from one node to another. This allows communication over long distances. No cellular or internet connection is needed.

The WisMesh RP2040 Starter Kit connects the Raspberry Pi Pico ecosystem with the Meshtastic network.

The WisMesh RP2040 Starter Kit is ideal for building off-grid LoRa mesh networks. It features the WisBlock RAK11310 Module, powered by the Raspberry Pi RP2040. Pre-flashed with Meshtastic firmware, the kit ensures a quick and easy setup. It is designed to support Meshtastic Client, Tracker, and Router Repeater roles.

Why You Need WisMesh RP2040 Starter Kit

The WisMesh RP2040 Starter Kit combines modular design with cutting-edge technology to help you deploy LoRa mesh networks for off-grid communication. Perfect for outdoor enthusiasts, IoT developers, and system integrators, this kit simplifies the process of building reliable Meshtastic networks.

Why it’s useful:

• Plug-and-Play – Pre-flashed with Meshtastic firmware for immediate use.
• Modular Design – Customize your setup with WisBlock Base Boards and additional sensor modules.
• Versatile Roles – Support for Client, Tracker, and Router Repeater roles.
• Durable and Secure – Compatible with Solar IP67 enclosures for outdoor use.

Build your ideal Meshtastic node with Meshtastic Designer. This online tool helps you select the ideal WisBlock modules and enclosures for different roles in your LoRa mesh network (e.g., Client, Tracker, Router).

You can also contact our team to help create your ideal Meshtastic setup.

Key Features of WisMesh RP2040 Starter Kit

Core Module

• RAK11310 WisBlock Core Module: Based on the Raspberry Pi Pico RP2040, pre-flashed with Meshtastic firmware for easy setup.

Base Boards

Choose the WisBlock Base Board for your needs:

• RAK19003 Mini Base Board: Compact 30 mm x 35 mm with two sensor slots, ideal for Client or Router roles.
• RAK19007 Base Board: Medium 30 mm x 60 mm with four sensor slots and one IO slot for added expandability.
• RAK19001 Base Board: Large 57 mm x 60 mm with six sensor slots and two IO slots, perfect for advanced configurations.

Enclosure Options

You can choose an IP67-rated enclosure with a solar option and multiple mounting brackets from the Unify Enclosure Collection.

You can also add other WisBlock modules to your selection. In the Meshtastic Documentation, you can find a list of supported WisBlock modules.

Sensor and Role-specific Modules

Customize your kit with modules designed for specific Meshtastic roles:

• Client Role:
  • RAK1921 OLED Display
• Tracker Role:
  • RAK12500 GNSS Location Module
  • RAK1904 Acceleration Sensor
• Combined Client-Tracker Role:
  • RAK1921 OLED Display
  • RAK12500 GNSS Location Module
  • RAK1904 Acceleration Sensor

• Meshtastic Router-Repeater Role with Ethernet & PoE

  • RAK13800 Ethernet Module

  • RAK19018 Ethernet PoE Module

Key Benefits of WisMesh RP2040 Starter Kit

The WisMesh RP2040 Starter Kit offers versatile, reliable, and easy-to-use features for building LoRa mesh networks.

• Quick Setup – Pre-flashed with Meshtastic firmware for immediate use.
• Customizable Design – Modular base boards and sensor options for tailored setups.
• Durable for Outdoors – Compatible with IP67 enclosures for secure, off-grid use.

Use Case #1

In emergency situations, the WisMesh RP2040 Starter Kit ensures reliable communication in remote areas where cellular networks fail. Teams can stay connected over long distances through a secure LoRa mesh network, enabling critical updates.

Use Case #2

For asset tracking, the WisMesh RP2040 Starter Kit with GNSS and accelerometer modules helps businesses monitor and locate valuable equipment in real time, even in off-grid locations.

What's in the Box

• 1x WisBlock Base Board (your choice)
• 1x RAK11310 WisBlock Core Module (RP2040)
• 1x SMA Rubber LoRa Antenna
• 1x IPEX to SMA Cable for LoRa Antenna
• 1x PCB Antenna for LoRa
• 1x USB Cable
• 1 set Screw
• Option to add sensor modules for your chosen role

How to Get Started with WisMesh RP2040 Starter Kit

• Meshtastic Installation and Usage Guide

• WisMesh MQTT Gateway Setup Guide

• WisMesh RP2040 Starter Kit Quick Start Guide

Frequently Asked Questions

How do I set up and use the WisMesh RP2040 Starter Kit for Meshtastic?

1. Assemble the Hardware

• Connect the RAK11310 Core Module to the WisBlock Base Board.
• Attach the LoRa antennas to their respective connectors.
• Optionally, add sensor modules or enclosures as needed.

2. Power the Device

• Connect the device to a USB power source using the provided USB cable.
• For portable applications, consider adding a Li-ion/LiPo battery and a solar charger for off-grid operation.

3. Configure the Device

• Use the Meshtastic Web Client or CLI to pair with your device.
• Follow the in-app instructions to set up your device's role (Client, Tracker, or Router Repeater) and customize settings.

4. Deploy and Test

• Place your device in the desired location.
• Use the Web UI or CLI to send test messages and verify connectivity within your mesh network.

For detailed instructions and troubleshooting, refer to the WisMesh RP2040 Starter Kit Quick Start Guide.

How do I flash or update the firmware on the WisMesh RP2040 Starter Kit?
To ensure your device runs the latest version of the Meshtastic firmware, download the latest firmware and follow the flashing guide available in the Meshtastic documentation. If issues arise, flashing the device with the latest firmware can help restore functionality. Learn more.
